823RTL-7
LED Stop/Turn/Tail, Oval, AMP, Narrow Flange-Mount 7.88″X3.31″, red, poly bag
823RTL-7
LED Stop/Turn/Tail, Oval, AMP, Narrow Flange-Mount 7.88″X3.31″, red, poly bag
LED STOP/TURN/TAIL
- Integral 30° angle silicone-sealed AMP receptacle.
- Meets DOT requirements in any horizontal / vertical / 360° position.
- Narrower than four-hole integrated flange.
- Oval Stop / Turn / Tail Light
- Recessed lens.
- See matching turn signal on Peterson LED Catalog page 16.
- Two mounting holes positioned at ends.
| 1321 | LED S/T/T Oval 7 Diode AMP Flange Mount w/ VENT |
| 823KR-7 | LED Stop/Turn/Tail, Oval, AMP, Flange-Mount Kit, 7.88″X3.63″, red, poly bag |
| 820R-7 | LED Stop/Turn/Tail, Oval, AMP, Grommet-Mount, 6.50″X2.25″, red, poly bag |
| 823R-7 | LED Stop/Turn/Tail, Oval, AMP, Flange-Mount 7.88″X3.63″, red, poly bag |
| 820KR-7 | LED Stop/Turn/Tail, Oval, AMP, Grommet-Mount Kit, 6.50″X2.25″, red, poly bag |
| M823RTL-7 | LED Stop/Turn/Tail, Oval, AMP, Narrow Flange-Mount 7.88″X3.31″, red, bulk pack |
| M823R-7 | LED Stop/Turn/Tail, Oval, AMP, Flange-Mount 7.88″X3.63″, red, bulk pack |
| M820R-7 | LED Stop/Turn/Tail, Oval, AMP, Grommet-Mount, 6.50″X2.25″ |
| Bulb Technology | LED |
| Bulb/Diode Count | 7 |
| California Prop65 Required | Yes |
| California Proposition 65 | Warning-cancer-and-or-reproductive-harm-www-p65warnings-ca-gov |
| Container Type | Poly-bag |
| Height | 3-63-inch |
| Integral Reflex | No |
| Length | 7-88-inch |
| Lens Color | Red |
| Light Color | Red |
| Maximum Voltage | 16-volts |
| Minimum Voltage | 9-volts |
| Mounting Type | Flange |
| Multi-Volt | No |
| Regulatory Compliance | DOT |
| Shape | Oval |
| Submersible | Yes |
| termination | AMP |
| Voltage | 12-volts |
| Width | 1-45-inch |
| Truck-Lite Interchange | 60252R |
| Truck-Lite Interchange | 60256R |
| Truck-Lite Interchange | 60266R |
| Truck-Lite Interchange | 66252R |
| Truck-Lite Interchange | 66256R |
| Truck-Lite Interchange | 66882R |
