782
107 Decibel Back-Up Alarm; stripped leads; box
782
107 Decibel Back-Up Alarm; stripped leads; box
- 107 Decibel Back-Up Alarm
- Regulatory Compliance: SAE J994 Type B
- 12-24 volt operating range.
- ABS housing and epoxy-sealed internal components for vibration and moisture protection.
- Available with stripped leads or .180 bullet terminals.
- Can be mounted to horizontal or vertical surfaces.
- Features the same form factor as Peterson’s existing 780 & 781 back-up alarms with louder alarm volume.
- Less than 0.8 amp draw.
- Meets SAE J994 Type B specifications.
- Unit may be grounded through mounting screw.
Standard Order Quantity: 1
| 782-BT2 | 107 Decibel Back-Up Alarm; .180 bullets; box |
| Multi-Volt | Yes |
| termination | Stripped Wire |
| Regulatory Compliance | SAE J994 Type B |
| Voltage | 12V / 24V |
| Container Type | Box |
| Mounting Type | Surface |
| Maximum Voltage | 24 Volts |
| Decibel Rating | 107 Decibels |
| Height | 3.25 Inch |
| Length | 4 Inch |
| Mounting Centers | 3.25 Inch |
| Width | 1.62 Inch |
| Truck-Lite Interchange | 92924 |
